Future Upgradable to android13

Panel Specification

Panel Size	65”
Response time	4ms
Visual Ratio	16:09
Panel Type	LG IPS Panel
Max Visual Area	1432 (H) × 807 (V) mm
Resolution	3840 (H) × 2160 (V)
Pixel pitch	0.372 × 0.372mm
Frequency	60Hz
Display Color	1.07B (10bit)
Color Saturability	72%
Contrast Ratio (Type)	4000:1
Viewing Angle	178° (H/V)
Light Source	DLED
Brightness	400cd/m2
Life Span	≥50,000hrs
Model No.	CQ65BIP

Audio-Video Parameters

Soundtrack	2.0
Power	≥20W

WiFi

Version	802.11ac/b/g/n/a/ax
Working Frequency	2.4GHz/5GHz
Working Distance	Up to 10 Meters
Remark	Via the Wireless Module S107B

Front Interface

USB 3.0	2
Touch USB	1
HDMI I	1
Type-C	1 (Full functionalities is Optional)

Power

Voltage	100~240V 50/60Hz 4A
Max. Power consumption	280W
Standby Power Consumption	≤0.5W

Environment

Working temperature	0°C~40°C
Working humidity	10%~90RH
Storage temperature	-20°C~60°C
Storage humidity	10%~90RH
Working Elevation	< 5000m

Touch Parameters

Touch Specification	Non-Contact Infrared sensing technology
Support Systems	Windows10/8/7/XP, Android, Linux, Mac OS, Chrome
Touch Point	20 Point touch
Min. Identifier	2mm
Respond time	≤10ms
Touch depth	+/-1
Writing display	Single Stylus pen two-color
Output Co-Ordinates	32767 (W) × 32767 (D)

System

System Version	Android 11.0
CPU	Quad Core A55 2.1GHz
GPU	Mali G52MP2
RAM	4GB / 8GB (Optional) System Memory
ROM	32GB / 128GB (Optional) System Storage

Wireless

Version	5.0
Working Frequency	2.4GHz
Working Distance	0~10m
Remark	via the wireless module S107B

Rear I/O Interface

HDMI In	2
USB 2.0	1
USB 3.0	2
USB Touch Port	1
Audio In	1
Line Out	1
Optical Out	1
RS232	1
LAN RJ45 IN	1
LAN RJ45 OUT	1

Structure

Bare Dimension	1788.4 × 896.6 × 87.2mm
Packing Dimension	1630 × 220 × 1050mm
Machine + Wall Mount thickness	116.5mm (WJ8600G)
VESA Hole size	600 × 400mm
Wall mounting Screw Specifications	M8 × 25mm
Net weight	45KG
Gross Weight	56KG
